| Varenummer | LTS220QC-F0J |
| Mærke | Samsung |
| Størrelse | 2.2 |
| Ansøgning | MPH |
| Løsning | 176×220 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 200:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | SAMSUNG |
| panel model | LTS220QC-F0J |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.2 inch |
| løsning | 176(RGB)×220 , QCIF+ |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 34.848×43.56 mm |
| omrids | 40.6×54.36×2.7 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 200:1 (Typ.)(Transmissive) |
| vise farver | 262K (6-bit), CIE193143% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/45/20 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S3PWLEDWithout Driver |
| signal interface | CPU, 21 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | MPH |
