| Varenummer | LMS241GF31 |
| Mærke | Samsung |
| Størrelse | 2.4 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 230 |
| CR | 500:1 |
| Farver | 65K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | SAMSUNG |
| panel model | LMS241GF31 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 36.72×48.96 mm |
| omrids | 42.72×60.26×3.92 mm |
| overflade | Hard coating (2H) |
| lysstyrke | 230 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 65K , CIE193155% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S4PWLEDWithout Driver |
| signal interface | CPU, 37 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | MPH |
