| Varenummer | PJ045IC-01F |
| Mærke | Innolux |
| Størrelse | 4.5 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 380 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | CHIMEI INNOLUX |
| panel model | PJ045IC-01F |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.5 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 55.512×98.688 mm |
| omrids | 60.04×108.72 mm |
| overflade | |
| lysstyrke | 380 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 30 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VDDIO/VCI) |
