| Varenummer | LP101WX1-SLB1 |
| Mærke | LG Display |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | Assembly |
| Lysstyrke | 340 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP101WX1-SLB1 |
| paneltype | a-Si TFT-LCD , Assembly |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| aktivt område | 216.96×135.6 mm |
| omrids | 262.7×178.7×7.1 mm |
| overflade | Anti Fingerprint |
| lysstyrke | 340 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Min.) |
| vise farver | 262K (6-bit) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
