| Varenummer | LP101WH4-SLP2 |
| Mærke | LG Display |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 380 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP101WH4-SLP2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 222.52×125.11 mm |
| omrids | 232.8×138.15×4.35 mm |
| overflade | Antiglare, Hard coating (3H), Antireflection |
| lysstyrke | 380 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
