| Varenummer | LP133WD2-SPB1 |
| Mærke | LG Display |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP133WD2-SPB1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 293.76×165.24 mm |
| omrids | 306.3×188.7 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 35 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP133WD2-SLB1 | LG Display | 13.3 | 1600×900 |
| LP133WD2-SPB1 | LG Display | 13.3 | 1600×900 |
| LP133WH1-TLC1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLE1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP133WX1-TLC1 | LG Display | 13.3 | 1280×800 |
| LP133WX1-TLN2 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLC1 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA6 | LG Display | 13.3 | 1280×800 |
| HB140WX1-400 | BOE | 14.0 | 1366×768 |
| LP140WF5-SPB3 | LG Display | 14.0 | 1920×1080 |
| LP140WH2-TLF3 | LG Display | 14.0 | 1366×768 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LTD133EV2F | TOSHIBA | 13.3 | 1280×800 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| LTN170X2-L02 | Samsung | 17.0 | 1440×900 |
| N133FGE-L31 | Innolux | 13.3 | 1600×900 |
| QD15TL04 Rev.04 | QDI | 15.4 | 1280×800 |
