| Varenummer | LP140WH1-TLD6 |
| Mærke | LG Display |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP140WH1-TLD6 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 309.399×173.952 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit) |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP140WD2-TLB1 | LG Display | 14.0 | 1600×900 |
| LP140WF5-SPB3 | LG Display | 14.0 | 1920×1080 |
| LP140WF6-SPB3 | LG Display | 14.0 | 1920×1080 |
| LP140WH1-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLD6 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLF3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM2 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| LP140WX1-TL02 | LG Display | 14.0 | 1280×768 |
| B133XW03 V4 | AUO | 13.3 | 1366×768 |
| B140XW02 V2 | AUO | 14.0 | 1366×768 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LP141WX3-TLN2 | LG Display | 14.1 | 1280×800 |
| LP156WH4-TPP1 | LG Display | 15.6 | 1366×768 |
| LP173WD1-TLC2 | LG Display | 17.3 | 1600×900 |
| LTD111EXCY | TOSHIBA | 11.1 | 1366×768 |
| LTN101AT03-801 | Samsung | 10.1 | 1366×768 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
