| Varenummer | LP150X09-B2K3 |
| Mærke | LG Display |
| Størrelse | 15.0 |
| Ansøgning | NBPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LP150X09-B2K3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 317.3×241.5×6 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (2H), Antireflection |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP150X05-A2M2 | LG Display | 15.0 | 1024×768 |
| LP150X08-A3 | LG Display | 15.0 | 1024×768 |
| LP150X08-B3 | LG Display | 15.0 | 1024×768 |
| LP150X08-TLA3 | LG Display | 15.0 | 1024×768 |
| LP150X08-TLA7 | LG Display | 15.0 | 1024×768 |
| LP150X08-TLAC | LG Display | 15.0 | 1024×768 |
| LP150X08-TLAD | LG Display | 15.0 | 1024×768 |
| LP150X09-A5K1 | LG Display | 15.0 | 1024×768 |
| LP150X09-B2K3 | LG Display | 15.0 | 1024×768 |
| LP150X09-B5K8 | LG Display | 15.0 | 1024×768 |
| B154EW01 V9 | AUO | 15.4 | 1280×800 |
| B173RW01 V5 | AUO | 17.3 | 1600×900 |
| LP140WH8-TPH1 | LG Display | 14.0 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LTN133AT27-205 | Samsung | 13.3 | 1366×768 |
| LTN141W1-L09 | Samsung | 14.1 | 1280×800 |
| LTN160AT01-A05 | Samsung | 16.0 | 1366×768 |
| N140BGE-L31 | Innolux | 14.0 | 1366×768 |
| N141C3-L04 | Innolux | 14.1 | 1440×900 |
| NT156WHM-N50 | BOE | 15.6 | 1366×768 |
