| Varenummer | TFTMD070021 |
| Mærke | JDI |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1100:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | JDI |
| panel model | TFTMD070021 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 98.7×160.8 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1100:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLED |
| signal interface | MIPI (4 data lanes) |
| Ansøgning | PAD |
| CLAA070LH01AW | CPT | 7.0 | 800×480 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| CLAP070WP03XG | CPT | 7.0 | 800×1280 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| LTL070NL01-801 | Samsung | 7.0 | 1024×600 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
| TFTMD070021 | JDI | 7.0 | 1200×1920 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HV121X03-100 | HYDIS | 12.1 | 1024×768 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLQA | LG Display | 9.7 | 1024×768 |
| LTL101AL06-003 | Samsung | 10.1 | 1280×800 |
| LTN097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
