| Varenummer | LQ070Y1LG12 |
| Mærke | SHARP |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ070Y1LG12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 175.4×112.5 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 16.2M (6-bit + FRC), CIE193172% |
| responstid | |
| synsvinkel | |
| lampe type | 1 pcsCCFL |
| signal interface | LVDS |
| Ansøgning | IA |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LQ070T5DR01 | SHARP | 7.0 | 480×240 |
| LQ070Y1LG12 | SHARP | 7.0 | 800×480 |
| LQ070Y3DG04 | SHARP | 7.0 | 800×480 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| LQ070Y5DG20 | SHARP | 7.0 | 800×480 |
| AA104XD02 | Mitsubishi | 10.4 | 1024×768 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| EL320.256-FD8 V2 | PLANAR | 4.8 | 320×256 |
| KCB104VG2CA-G43 | Kyocera | 10.4 | 640×480 |
| LM104VC1T51H | SHARP | 10.4 | 640×480 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| NL6448BC33-53 | NLT | 10.4 | 640×480 |
| PD064VT8 | E Ink | 6.4 | 640×480 |
| TCG075VGLDA-G50 | Kyocera | 7.5 | 640×480 |
