| Varenummer | LQ070Y5DG20 |
| Mærke | SHARP |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 100:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ070Y5DG20 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 156×82.8 mm |
| omrids | 167×93×7.5 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 30/50 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/65/60 (Typ.)(CR≥5)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 50 pins |
| indgangsspænding | 5.3/3.3/15/-12V (Typ.)(VSHA/VSHD/VDD/VEE) |
| Ansøgning | CNS |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070T3AG02 | SHARP | 7.0 | 480×234 |
| LQ070T5AR01 | SHARP | 7.0 | 480×234 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG12 | SHARP | 7.0 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| DD070NA-02A | Innolux | 7.0 | 800×480 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ058T5DG31 | SHARP | 5.8 | 480×240 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| PD050VX6 | E Ink | 5.0 | 640×480 |
| PW070XUA | E Ink | 7.0 | 480×234 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
