| Varenummer | TCG035QVLPDANN-GN50 |
| Mærke | Kyocera |
| Størrelse | 3.5 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Kyocera |
| panel model | TCG035QVLPDANN-GN50 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.56×52.92 mm |
| omrids | 76.9×63.9×5.1 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8/22 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
