| Varenummer | LS024J3LX01 |
| Mærke | SHARP |
| Størrelse | 2.4 |
| Ansøgning | MPH |
| Løsning | 320×480 |
| Sammensætning | LCM |
| Lysstyrke | 370 |
| CR | 540:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI |
| panel mærke | SHARP |
| panel model | LS024J3LX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 320(RGB)×480 , HVGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 33.6×50.4 mm |
| omrids | 38.6×60.4 mm |
| overflade | |
| lysstyrke | 370 cd/m² (Typ.) |
| kontrastforhold | 540:1 (Typ.) |
| vise farver | 16.7M , CIE193181% |
| responstid | 7/15 (Typ.)(Tr/Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 4S1PWLEDWithout Driver |
| signal interface | MDDI (2 data lanes), 24 pins |
| indgangsspænding | 1.65/2.6 (Typ.)(VDD/VDDI) |
| Ansøgning | MPH |
