| Varenummer | LS024Q3UX05 |
| Mærke | SHARP |
| Størrelse | 2.4 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | SHARP |
| panel model | LS024Q3UX05 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 36.72×48.96 mm |
| omrids | 42.2×69.4 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K , CIE193170% |
| responstid | 11/24 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S5PWLEDWithout Driver |
| signal interface | CPU, 37 pins |
| indgangsspænding | 2.62/2.62V (Typ.)(VDDIO/VDC) |
| Ansøgning | HHP |
