| Varenummer | LQ055K3SX02 |
| Mærke | SHARP |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LQ055K3SX02 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 72.3×130.39 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| LQ055K3SX02 | SHARP | 5.5 | 720×1280 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LQ055W1GC01 | SHARP | 5.5 | 1024×600 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
| AMEJ006 | Samsung | 2.8 | 240×400 |
| AMS320FH01-0 | Samsung | 3.2 | 240×400 |
| CLAN050LE61 1XE | CPT | 5.0 | 540×960 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| H027QT01 | AUO | 2.7 | 208×320 |
| H446TAN01.1 | AUO | 4.5 | 720×1280 |
| LMS220GF08 | Samsung | 2.2 | 240×320 |
| LMS316CC01 | Samsung | 3.2 | 640×360 |
| LS032B7LX02 | SHARP | 3.2 | 320×480 |
| TM022HDH31 | Tianma | 2.2 | 240×320 |
