| Varenummer | LS026Q3DX01 |
| Mærke | SHARP |
| Størrelse | 2.6 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 160 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | MDDI |
| panel mærke | SHARP |
| panel model | LS026Q3DX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 2.6 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 38.88×51.84 mm |
| omrids | 45.7×64.45 mm |
| overflade | |
| lysstyrke | 160 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 55 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S3PWLEDWithout Driver |
| signal interface | MDDI (2 data lanes), 61 pins |
| indgangsspænding | 1.8/2.9V (Typ.)(VDDIO/VDDC) |
