| Varenummer | AMS410GJ02-0 |
| Mærke | Samsung |
| Størrelse | 4.1 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | OLED |
| Lysstyrke | 270 |
| CR | 100000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | TTL |
| panel mærke | SAMSUNG SMD |
| panel model | AMS410GJ02-0 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 4.1 inch |
| løsning | 480RG(BG)×800 , WVGA |
| aktivt område | 53.28×88.8 mm |
| omrids | 58.44×98.7 mm |
| overflade | Hard coating |
| lysstyrke | 270 cd/m² (Typ.) |
| kontrastforhold | 100000 : 1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931105% |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | Built-in S6E63M0 |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| indgangsspænding | 2.6/2.8V (Typ.)(VDD3/VCI) |
| Ansøgning | MPH |
