| Varenummer | E555HBM2 |
| Mærke | EDO |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | OLED |
| Lysstyrke | 300 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | EDO |
| panel model | E555HBM2 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 5.5 inch |
| løsning | 720(RGB)×1280 , WXGA |
| aktivt område | 69.12×122.88 mm |
| omrids | 72.8×131.2 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 3000 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931105% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| driver ic | COG Built-in SH1386 |
| signal interface | MIPI (4 data lanes), 30 pins |
| indgangsspænding | 3.3/4.6/6.1/-3.5V (Typ.)(VCI/VELVDD/VSP/VELVSS) |
| Ansøgning | MPH |
