| Varenummer | LS025A8DZ01S |
| Mærke | SHARP |
| Størrelse | 2.5 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 310 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | SHARP |
| panel model | LS025A8DZ01S |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 2.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | ASV, Normally Black, Transflective |
| aktivt område | 49.9×37.4 mm |
| overflade | Hard coating (2H) |
| lysstyrke | 310 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit) |
| responstid | 25/25 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Serial RGB (8-bit), 45 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | DSC |
| A025DN01 V3 | AUO | 2.5 | 320×240 |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| LH250Q01-TH02 | LG Display | 2.5 | 320×240 |
| LMS246GF06 | Samsung | 2.5 | 320×240 |
| LMS250GF01 | Samsung | 2.5 | |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TD025THEE6 | TPO | 2.5 | 640×240 |
| TD025THEEA | TPO | 2.5 | 640×240 |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| A027DN03 V7 | AUO | 2.7 | 320×240 |
| L3F04X-80300C | Epson | 0.48 | 1024×768 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TD025THEA3 | TPO | 2.5 | 320×240 |
| TD025THEG1 | TPO | 2.5 | 320×240 |
| TM027CDH04 | Tianma | 2.7 | 320×240 |
