| Varenummer | LS037V3DX01 |
| Mærke | SHARP |
| Størrelse | 3.7 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LS037V3DX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 3.7 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 74.88×56.16 mm |
| omrids | 85×71.8 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 51 pins |
| indgangsspænding | 5.0/3.3/9.8/-6.5V (Typ.)(VSHD/VSHA/VDD/GVSS) |
| Ansøgning | IA |
