| Varenummer | LS050T1SX18 |
| Mærke | Sharp |
| Størrelse | 5.0 |
| Ansøgning | Mobile Phone |
| Løsning | 1080×1920 |
| Sammensætning | CG-Silicon, LCM |
| Lysstyrke | |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 6S2P |
| Interface | MIPI |
| panel mærke | Sharp |
| panel model | LS050T1SX18 |
| panelstørrelse | 5.0" |
| paneltype | CG-Silicon, LCM |
| løsning | 1080(RGB)×1920, FHD, 445PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 61.641(W)×109.584(H) mm |
| bezel åbning | - |
| konturstørrelse | 63.64(W)×116.224(H) ×1.16(D) mm |
| overflade | - |
| lysstyrke | 480 cd/m² (Typ.) |
| kontrastforhold | 1500:1 (Typ.) (TM) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10) |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 35 (Max.)(Tr+Td) |
| vise farver | 16.7M 95% NTSC |
| lampe type | 6S2P WLED , Without Driver |
| frekvens | 60Hz |
| berøringsskærm | PCAP |
| panelvægt | 14.0g (Typ.) |
| Ansøgning | Mobile Phone |
| signal interface | MIPI (4 data lanes) , 40 pins Connector |
| indgangsspænding | 1.8/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| miljø | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
