| Varenummer | LQ050T1SX02 |
| Mærke | SHARP |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 460 |
| CR | 1300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LQ050T1SX02 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 61.641×109.584 mm |
| omrids | 64.041×116.224×1.13 mm |
| overflade | |
| lysstyrke | 460 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193195% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S2PWLEDWithout Driver |
| signal interface | MIPI, 30 pins |
| indgangsspænding | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| Ansøgning | MPH |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050T1SX02 | SHARP | 5.0 | 1080×1920 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| 990001086 | Innolux | 3.0 | |
| AMFN888 | Samsung | 3.1 | 480×800 |
| DLC0300AMG | Other | 3.0 | 240×400 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LS043K1SX02 | SHARP | 4.3 | 720×1280 |
| LS043T1LX01A | SHARP | 4.3 | 540×960 |
| LT031MDZ4000 | JDI | 3.1 | 720×720 |
| LTP280QV-E01 | Samsung | 2.8 | 240×320 |
| TM032PDZ16B | Tianma | 3.2 | 320×480 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
