| Varenummer | LS055R1SX04 |
| Mærke | SHARP |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1440×2560 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS055R1SX04 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 1440(RGB)×2560 , Quad-HD |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.94×128.49×1.45 mm |
| overflade | |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S2PWLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 50 pins |
| indgangsspænding | 1.8/5.75/-5.75V (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | MPH |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| CLAF050LN41 TXX | CPT | 5.0 | 540×960 |
| CLAN050LH21 1XB | CPT | 5.0 | 540×960 |
| H429AL01 V0 | AUO | 4.3 | 540×960 |
| LH450WX1-SD01 | LG Display | 4.5 | 720×1280 |
| LH550WF2-SD01 | LG Display | 5.5 | 1080×1920 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
