| Varenummer | LS063R1SX01 |
| Mærke | SHARP |
| Størrelse | 6.3 |
| Ansøgning | MPH |
| Løsning | 1440×2560 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS063R1SX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 6.3 inch |
| løsning | 1440(RGB)×2560 , Quad-HD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 78.84×140.16 mm |
| omrids | 80.84×148.92×1.58 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S2PWLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 60 pins |
| indgangsspænding | 1.8/5.9/-5.9V (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | MPH |
