| Varenummer | HVA32WV1-D00 |
| Mærke | HYDIS |
| Størrelse | 3.2 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | HYDIS |
| panel model | HVA32WV1-D00 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 3.2 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 41.76×69.6 mm |
| omrids | 45.36×77.6 mm |
| overflade | Without Polarizer |
| glas dybde | 0.25+0.25 mm |
| transmissivitet | 3.3% (Typ.)(with Polarizer) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 33 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Suggest LG4572, LG4573 |
| Ansøgning | MPH |
