| Varenummer | LT044MDW7000 |
| Mærke | TOSHIBA |
| Størrelse | 4.5 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | TOSHIBA |
| panel model | LT044MDW7000 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.5 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 55.62×98.88 mm |
| omrids | 58.42×107.8 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193165% |
| responstid | 25/25 (Typ.)(Tr/Td); 55 (Typ.)(G to G) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 1.8/2.85V (Typ.)(VDDI/VDD) |
| Ansøgning | MPH |
