| Varenummer | CLAN055WA41 3XB |
| Mærke | CPT |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | CPT |
| panel model | CLAN055WA41 3XB 1 Compatible model |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.5 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.84×128.96 mm |
| overflade | Hard coating |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 5.0% (Typ.)(with APCF) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | COG Suggest OTM1283A-C35 |
| indgangsspænding | 1.8/2.8/2.8V (Typ.)(VDDI/VCIVCC) |
| Ansøgning | MPH |
