| Varenummer | DLC0400KZG |
| Mærke | Other |
| Størrelse | 4.0 |
| Ansøgning | MPH |
| Løsning | 640×1136 |
| Sammensætning | LCM |
| Lysstyrke | 580 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | DLC |
| panel model | DLC0400KZG 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 640(RGB)×1136 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 49.92×88.608 mm |
| omrids | 53.8×96.4×1.53 mm |
| overflade | |
| lysstyrke | 580 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 20 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S2PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 22 pins |
| indgangsspænding | 1.8/5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
