| Varenummer | H345VW01 V0 |
| Mærke | AUO |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | H345VW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | VA, Normally Black, Transmissive |
| aktivt område | 45.072×75.12 mm |
| omrids | 49.02×83.52 mm |
| overflade | |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Min.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 50/50 (Max.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S6PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 24 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VDDI/VDD) |
| Ansøgning | MPH |
