| Varenummer | G220SVN01.0 |
| Mærke | AUO |
| Størrelse | 22.0 |
| Ansøgning | GM |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 2000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | G220SVN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 22.0 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 473.76×296.1 mm |
| omrids | 493.7×320.1×15.75 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193170% |
| responstid | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
