| Varenummer | LTA220W1-L02 |
| Mærke | Samsung |
| Størrelse | 22.0 |
| Ansøgning | LCTV |
| Løsning | 1280×720 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTA220W1-L02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 22.0 inch |
| løsning | 1280(RGB)×720 , WXGA |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 487.58×274.32 mm |
| omrids | 525.6×307.9 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/8 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
