| Varenummer | LTE480WV-F01 |
| Mærke | Samsung |
| Størrelse | 4.8 |
| Ansøgning | PND |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LTE480WV-F01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.8 inch |
| løsning | 800×480(RGB) , WVGA |
| visningstilstand | TN, Normally White, TMR |
| aktivt område | 103.8×62.28 mm |
| omrids | 118.2×74.28 mm |
| overflade | |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 300 : 1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 22.5 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | PND |
| 43WQW3H | SII | 4.3 | 480×272 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| LB035Q02-TD01 | LG Display | 3.5 | 320×240 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ043T1DG04 | SHARP | 4.3 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
