| Varenummer | LTL090CL01-002 |
| Mærke | Samsung |
| Størrelse | 9.0 |
| Ansøgning | PAD |
| Løsning | 1920×1280 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SAMSUNG |
| panel model | LTL090CL01-002 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.0 inch |
| løsning | 1920(RGB)×1280 |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 190.08×126.72 mm |
| omrids | 200.91×141.21×2.73 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
