| Varenummer | TV080X0M-NS0 |
| Mærke | BOE |
| Størrelse | 8.0 |
| Ansøgning | PAD |
| Løsning | 768×1024 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | TV080X0M-NS0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 768(RGB)×1024 , XGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 121.882×162.509 mm |
| omrids | 128.142×173.739 mm |
| overflade | |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193171% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 1.8/5.4/-5.4V (Typ.)(Vio/Vsn/Vsp) |
