| Varenummer | LQ101R1SX01A |
| Mærke | SHARP |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 2560×1600 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LQ101R1SX01A |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 2560(RGB)×1600 , WQXGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 228×148.5×4.6 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S6PWLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
