| Varenummer | LTM215HT04 |
| Mærke | Samsung |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM215HT04 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.64×268.11 mm |
| omrids | 495.6×292.2×10.7 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S3PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM215WF8-TLA1 | LG Display | 21.5 | 1920×1080 |
| LTM213U3-L07 | Samsung | 21.3 | 1600×1200 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L02 | Samsung | 21.3 | 1600×1200 |
| LTM215HL01 | Samsung | 21.5 | 1920×1080 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| LTM215HT05 | Samsung | 21.5 | 1920×1080 |
| M215HJJ-L30 Rev.B1 | Innolux | 21.5 | 1920×1080 |
| LTM150XS-T01 | Samsung | 15.0 | 1024×768 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM230HT02 | Samsung | 23.0 | 1920×1080 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M200RW01 V6 | AUO | 20.0 | 1600×900 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| TM190MFS01 | Tianma | 19.0 | 1440×900 |
