| Varenummer | LTN133W1-L01 |
| Mærke | Samsung |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN133W1-L01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 286.08×178.8 mm |
| omrids | 299×195×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 40/40/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
| Ansøgning | NBPC |
| LTN133AT01-003 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-S02 | Samsung | 13.3 | 1280×800 |
| LTN133AT15-G01 | Samsung | 13.3 | 1280×800 |
| LTN133AT16-L01 | Samsung | 13.3 | 1280×800 |
| LTN133AT17-W01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-803 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-B01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-C01 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-205 | Samsung | 13.3 | 1366×768 |
| LTN133HL01-301 | Samsung | 13.3 | 1920×1080 |
| B121EW03 V6 | AUO | 12.1 | 1280×800 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B140XTN03.4 | AUO | 14.0 | 1366×768 |
| CLAA154WB04A | CPT | 15.4 | 1280×800 |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP156WF6-SPH3 | LG Display | 15.6 | 1920×1080 |
| LTN140KT06-T01 | Samsung | 14.0 | 1600×900 |
| LTN154X5-L02 | Samsung | 15.4 | 1280×800 |
| N154I2-L05 | Innolux | 15.4 | 1280×800 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
