| Varenummer | LTN160HT02-001 |
| Mærke | Samsung |
| Størrelse | 16.0 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | RGB LED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN160HT02-001 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 16.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 353.28×198.72 mm |
| omrids | 365×217 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 40%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), Adobe100% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 75/75/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | RGB LEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| HSD173PUW1-A00 | HannStar | 17.3 | 1920×1080 |
| LP133WH2-TLHA | LG Display | 13.3 | 1366×768 |
| LP140WF5-SPB3 | LG Display | 14.0 | 1920×1080 |
| LP171WU1-TLA1 | LG Display | 17.1 | 1920×1200 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| LTN150XB-L02 | Samsung | 15.0 | 1024×768 |
| LTN154X3-L04 | Samsung | 15.4 | 1280×800 |
| N140BGE-L32 | Innolux | 14.0 | 1366×768 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
