| Varenummer | LTV280QV-F02 |
| Mærke | Samsung |
| Størrelse | 2.8 |
| Ansøgning | DVC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 250:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LTV280QV-F02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 61.44×34.32 mm |
| omrids | 68.41×45.23×2.97 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 4S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 64 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DVC |
| 990000553 | TPO | 3.5 | 320×240 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| COM48T4Mxxxxx | ORTUSTECH | 4.8 | 1920×1080 |
| LS032V8DY01 | SHARP | 3.2 | 640×480 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
