| Varenummer | PD035QX2 |
| Mærke | E Ink |
| Størrelse | 3.5 |
| Ansøgning | DVC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | Parallel/Serial |
| panel mærke | PVI |
| panel model | PD035QX2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 78.3×64.5×3.8 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S3PWLEDWithout Driver |
| signal interface | Digital RGB (8/24-bit) + SPI, CCIR601/656, 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDDA/VDD) |
| rohs: | |
