| Varenummer | A035CN02 V1 |
| Mærke | AUO |
| Størrelse | 3.5 |
| Ansøgning | DVC |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 240 |
| CR | 150:1 |
| Farver | |
| Baggrundsbelysning | WLED |
| Interface | Analog |
| panel mærke | AU Optronics |
| panel model | A035CN02 V1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 72×50.544 mm |
| omrids | 83×60.5 mm |
| overflade | |
| lysstyrke | 240 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.) |
| vise farver | |
| responstid | 20/30 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/10/30 (Min.)(CR≥10)(L/R/U/D) |
| lampe type | 3S2PWLEDWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 5/5/15/5V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | DVC |
