| Varenummer | LTY460JN12 |
| Mærke | Other |
| Størrelse | 46 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 550 |
| CR | 8000:1 |
| Farver | 1.06B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | No Brand |
| panel model | LTY460JN12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 46 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | SVA, Normally Black, Transmissive |
| aktivt område | 1018.08×572.67 mm |
| omrids | 1029.9×585.5 mm, Videowall Seam 11.7 mm |
| overflade | Hard coating (2H), Reflection 1.4% (Max.) |
| lysstyrke | 550 cd/m² (Typ.) |
| kontrastforhold | 8000:1 (Typ.) |
| vise farver | 1.06B (8-bit + Dithering), CIE193176% |
| responstid | 3.5 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz (60Hz Input) |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 50 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LTI460HN07 | Samsung | 46 | 1920×1080 |
| LTY460HB01 | Samsung | 46 | 1920×1080 |
| LTY460HH-LH2 | Samsung | 46 | 1920×1080 |
| LTY460HN06 | Samsung | 46 | 1920×1080 |
| LTY460HQ05-A01 | Samsung | 46 | 1920×1080 |
| LTY460HS-LH2 | Samsung | 46 | 1920×1080 |
| LTY460HT-LH1 | Samsung | 46 | 1920×1080 |
| LTY460JN12 | Other | 46 | 1920×1080 |
| P460HVN01.1 | AUO | 46 | 1920×1080 |
| T460HW02 V1 | AUO | 46 | 1920×1080 |
| LC260EUN-SDP1 | LG Display | 26.0 | 1920×1080 |
| LC370EUN-SDF1 | LG Display | 37 | 1920×1080 |
| LC470WUF-SCA2 | LG Display | 47 | 1920×1080 |
| LTA320W1-L02 | Samsung | 31.5 | 1280×768 |
| LTY520HE06 | Samsung | 52 | 1920×1080 |
| T315XW06 V5 | AUO | 31.5 | 1366×768 |
| T390XVN01.0 CELL | AUO | 39 | 1366×768 |
| T460HW07 V4 | AUO | 46 | 1920×1080 |
| T645HW02 V3 | AUO | 65 | 1920×1080 |
| V420H1-LE1 | Innolux | 42 | 1920×1080 |
