| Varenummer | M101NWN8 R0 |
| Mærke | IVO |
| Størrelse | 10.1 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | IVO |
| panel model | M101NWN8 R0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222.521×125.107 mm |
| omrids | 243×146.5×3.6 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 3/5 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LTN101NT06-W03 | Samsung | 10.1 | 1024×600 |
| M101NWN8 R0 | IVO | 10.1 | 1366×768 |
| M101NWT2 R0 | IVO | 10.1 | 1024×600 |
| M101NWT2 R1 | IVO | 10.1 | 1024×600 |
| M101NWT2 R2 | IVO | 10.1 | 1024×600 |
| M101NWT2 R3 | IVO | 10.1 | 1024×600 |
| M101NWT4 R3 | IVO | 10.1 | 1024×600 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| M101NWWB R8 | IVO | 10.1 | 1280×800 |
| YXD101301000-60 | SEBO | 10.1 | 1024×600 |
| B140XW01 V4 | AUO | 14.0 | 1366×768 |
| B156RW01 V0 | AUO | 15.6 | 1600×900 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| LP141WX5-TLC1 | LG Display | 14.1 | 1280×800 |
| LP156WF3-SLB2 | LG Display | 15.6 | 1920×1080 |
| LP171WP4-TLP1 | LG Display | 17.1 | 1440×900 |
| LT121SU-121 | Samsung | 12.1 | 800×600 |
| LTN133HL01-301 | Samsung | 13.3 | 1920×1080 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
| N140O6-L02 | Innolux | 14.0 | 1600×900 |
