| Varenummer | YXD101301000-60 |
| Mærke | SEBO |
| Størrelse | 10.1 |
| Ansøgning | CNS |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 600:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SEBO |
| panel model | YXD101301000-60 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222.72×125.28 mm |
| omrids | 235×149.2×6.3 mm |
| overflade | Antiglare |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193152% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 60 pins |
| indgangsspænding | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
