| Varenummer | M170XW01 V3 |
| Mærke | AUO |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M170XW01 V3 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×768 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 370.56×222.336 mm |
| omrids | 404×248.5×17.8 mm |
| overflade | Glare (Haze 0%), Hard coating (2H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC) |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
