| Varenummer | NL12876AC39-01 |
| Mærke | NLT |
| Størrelse | 23.0 |
| Ansøgning | DMPC |
| Løsning | 1280×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 350:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL12876AC39-01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 23.0 inch |
| løsning | 1280(RGB)×768 , WXGA |
| visningstilstand | UA-SFT, Normally Black, Transmissive |
| aktivt område | 501.12×300.672 mm |
| omrids | 528×326 mm |
| overflade | Hard coating (2H), Antireflection |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 10/13 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
