| Varenummer | M240HW01 V2 |
| Mærke | AUO |
| Størrelse | 24.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M240HW01 V2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 24.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 531.36×298.89 mm |
| omrids | 556×323.2×16.8 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 3.5/1.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| M240HTN01.2 | AUO | 24.0 | 1920×1080 |
| M240HVN02.0 | AUO | 24.0 | 1920×1080 |
| M240HW01 V0 | AUO | 24.0 | 1920×1080 |
| M240HW01 V1 | AUO | 24.0 | 1920×1080 |
| M240HW01 V2 | AUO | 24.0 | 1920×1080 |
| M240HW01 VB | AUO | 24.0 | 1920×1080 |
| M240HW01 VC | AUO | 24.0 | 1920×1080 |
| M240HW02 V1 | AUO | 24.0 | 1920×1080 |
| M240HW02 V6 | AUO | 24.0 | 1920×1080 |
| M240HW02 V7 | AUO | 24.0 | 1920×1080 |
| CLAA150XP01Q | CPT | 15.0 | 1024×768 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| LM190E08-TLG4 | LG Display | 19.0 | 1280×1024 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM250WW1-SSA1 | LG Display | 25.0 | 2560×1080 |
| LM300WQ6-SLA1 | LG Display | 30.0 | 2560×1600 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
