| Varenummer | NL128102BC23-03 |
| Mærke | NLT |
| Størrelse | 15.4 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 240 |
| CR | 250:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL128102BC23-03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 305.28×244.224 mm |
| omrids | 340×269 mm |
| overflade | Hard coating (3H), Antireflection |
| lysstyrke | 240 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193160% |
| responstid | 6/41 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 50 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
