| Varenummer | MV236FHB-N10 |
| Mærke | BOE |
| Størrelse | 23.6 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | MV236FHB-N10 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 23.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 521.28×293.22 mm |
| omrids | 529.66×303.16 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| glas dybde | 0.50+0.50 mm |
| transmissivitet | 5.3% (Typ.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
