| Varenummer | N070ICE-GB1 |
| Mærke | Innolux |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | INNOLUX |
| panel model | N070ICE-GB1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.2×150.72 mm |
| omrids | 105.62×163.27×3.95 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 14/11 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 36 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(VCC/VDD) |
| Ansøgning | PAD |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| TR-LM7WR3PS | Panasonic | 7.0 | 480×234 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
